PS114
If you’re thinking of changing your power supply and are looking for something water resistant, durable, and with a power of at least 0.9, the PS114 Regulated Switch Mode Power Supply is made for you.
With 110/240V AC Input Voltage and a power efficiency of at least 87%, this power supply is ready to keep the music flowing.
Quick Links
| Type: | Regulated switching mode power supply (≤10A, 13V DC) |
| Waterproof: | Yes – IPx5 |
| Input Voltage: | 100-240V AC (power input auto sensing/switching) |
| Input Frequency: | 50/60 Hz |
| Efficiency: | ≥87% |
| Power Consumption: | ≤0.5W (at 240V AC) |
| Power Factor: | ≥0.9 (at full load) |
| Short Circuit Protection: | Continuous |
| Output Plug: | 2x female spade connectors (+13V DC (red), Neg (black)) |
| Output Voltage: | 12V DC regulated |
| Output Current: | 4A |
| Ripple & Noise: | 260mV (max) |
| Voltage Accuracy: | ±5% |
| Line Regulation: | ±5% |
| Load Regulation | ±5% |
| Operating Temperature: | -20°C – 70°C |
| Storage Temperature: | -20°C – 85°C |
| Dimensions: | L:160 mm W:51.5 mm H:38.6 mm |
| Certifications: | UL1563, UL1310, CSA, CE |
| Additional Features: | Over Voltage Protection, Over Current Protection |
| Over Temperature Protection |
